HURCO VMX84i 4-Axis CNC VERTICAL MACHINING CENTER

Stock #: Q11560-4

Brand: HURCO
Model: VMX84i
Type: Machining Centers, Vertical
Condition: Excellent
Year: 2015

Equipped With:



Hurco WinMax Dual Screen CNC, Hurco 10" H320 4th Axis CNC Rotary Table, Renishaw Part and Tool Probe, 40 Station Automatic Tool Changer, Metal Way Covers, Deluxe Chip Conveyor, Optional High Pressure Coolant System.

-- 2,138 Spindle Hours. Appears to be in Excellent Condition. Came from a Super Clean High-Tech shop that was Closed Down. New Replacement Cost 'As Equipped' is $ 290,000.




Specifications:
CNC Control yes
Type of CNC Control Hurco WinMax Dual Screen CNC
# Axis 4
Table Size 86" x 34"
Table Load Capacity 5,000 LBS
X-Axis (Longitudinal Travel) 84"
Y-Axis (Cross Travel) 34"
Z-Axis (Vertical Travel) 30"
Max/Min Clearance Table Top to Spindle Nose 35.8" / 5.8"
Feed Rates, All Axes 530 IPM
X-Axis Rapid Traverse Rate 709 IPM
Y-Axis Rapid Traverse Rate 709 IPM
Z-Axis Rapid Traverse Rate 530 IPM
Spindle Horsepower 24 HP
Max Spindle Speed 12,000 RPM
Spindle Taper 40 Taper Big Plus
Coolant Thru Spindle yes
Automatic Tool Changer Capacity (ATC) 40
Automatic Tool Changer Style Side-Mount
Max Tool Length 11.8"
Max Tool Diameter 2.95"
Max Tool Weight 15.4 LBS
Machine Spindle Hours 2,138
Electrics 460/3/60
Operating Floor Space (LxWxH) 298" x 175" x 128"
Approximate Machine Weight 40,000 LBS
CONDITION: This Machine Appears to be in Excellent Condition ! Only 2,138 Spindle Hours

HURCO VMX84i 4-Axis CNC VERTICAL MACHINING CENTER

HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.
  • HURCO VMX84i CNC 4-AXIS VERTICAL MACHINING CENTER, Hurco WinMax Dual Screen CNC, 10" Hurco H320 4th Axis Rotary Table, 86" x 34" Table, X=84", Y=34", Z=30", 40 Taper, 24 HP, 12000 RPM, 40 ATC, TSC, HPC, Tool and Part Probes, Chip Conveyor, New 2015, Low Hours, Super Clean.

Machine Videos

Share:

Print Details

Fields marked with * are required.

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    Fields marked with * are required.


      This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

      Brand
      HURCO

      Model
      VMX84i

      Type
      Machining Centers, Vertical

      Stock #
      Q11560-4

      Condition
      Excellent

      Year
      2015

      Request a Quote Today!

      Get Started

      Equipped With

      Hurco WinMax Dual Screen CNC, Hurco 10" H320 4th Axis CNC Rotary Table, Renishaw Part and Tool Probe, 40 Station Automatic Tool Changer, Metal Way Covers, Deluxe Chip Conveyor, Optional High Pressure Coolant System.

      -- 2,138 Spindle Hours. Appears to be in Excellent Condition. Came from a Super Clean High-Tech shop that was Closed Down. New Replacement Cost 'As Equipped' is $ 290,000.


      Specifications
      CNC Control yes
      Type of CNC Control Hurco WinMax Dual Screen CNC
      # Axis 4
      Table Size 86" x 34"
      Table Load Capacity 5,000 LBS
      X-Axis (Longitudinal Travel) 84"
      Y-Axis (Cross Travel) 34"
      Z-Axis (Vertical Travel) 30"
      Max/Min Clearance Table Top to Spindle Nose 35.8" / 5.8"
      Feed Rates, All Axes 530 IPM
      X-Axis Rapid Traverse Rate 709 IPM
      Y-Axis Rapid Traverse Rate 709 IPM
      Z-Axis Rapid Traverse Rate 530 IPM
      Spindle Horsepower 24 HP
      Max Spindle Speed 12,000 RPM
      Spindle Taper 40 Taper Big Plus
      Coolant Thru Spindle yes
      Automatic Tool Changer Capacity (ATC) 40
      Automatic Tool Changer Style Side-Mount
      Max Tool Length 11.8"
      Max Tool Diameter 2.95"
      Max Tool Weight 15.4 LBS
      Machine Spindle Hours 2,138
      Electrics 460/3/60
      Operating Floor Space (LxWxH) 298" x 175" x 128"
      Approximate Machine Weight 40,000 LBS
      CONDITION: This Machine Appears to be in Excellent Condition ! Only 2,138 Spindle Hours
